Penetrator MK.II

Unread postAuthor: foilboy » Thu Mar 22, 2012 8:21 pm

Here's my shortened version of my previous cannon. I've reduced the chamber by a whole hell of a lot from 2" to 1" sch 80. The barrel is a cold steel blow gun barrel extension sleeved in 1"ID rubber tubing, sleeved in 1" sch 40 PVC. The QEV is a Fastenal 1/2". I used a schrader valve with a check valve in behind it so that I could fill the chamber with a bike pump. Works like a charm, and I can always swap out barrels for a longer one. Only thing left to do is to make a bracket to stabilize and reinforce the barrel and chamber.




Here's the link to the MK.I
http://www.spudfiles.com/forums/viewtop ... tml#323681
  • 0


foilboy
Private
Private

Posts: 11
Joined: Thu Jul 14, 2011 2:11 pm
Reputation: 0

Unread postAuthor: jackssmirkingrevenge » Fri Mar 23, 2012 1:35 am

That's some nice penetration :) you should think about getting a track pump and moving to the 200-250 psi range if your chamber can take it.
  • 0

User avatar
jackssmirkingrevenge
Donating Member
Donating Member

Posts: 24225
Joined: Thu Mar 15, 2007 11:28 pm
Country: Holy See (Vatican City State) (va)
Reputation: 66
