multi-shot breechloading pneumatic

Built a pneumatic cannon? Then post it here! This section is for completed, finished cannons that you have built. Please include pictures and information.
Sponsored
  • Author
    Message

multi-shot breechloading pneumatic

Unread postAuthor: iknowmy3tables » Mon Jan 01, 2007 10:02 pm

Man what a day, today I made this new gun from spare parts lying around
Image this is the full pic of the cannon, the main air tank is made from 3’ pvc, the reservoir consist of the stock and handle
There is a 1” valve and a 1/2” by opening or closing the 1” I can shoot 1 more powerful shot, or multiple weaker shots
Eeeeeewwww :oops: now comes the story behind my gun. Okay as I was gluing the stock together but I couldn’t find a rubber mallet so I used a baby metal hammer within reach, I began to hammer and looked away but then realized I cracked the tee I freaked out and took off the stock but I couldn’t take it apart and I didn’t have a replacement, then with little time I cut a 1” pipe with an slant edge made so air could flow throughout the tee, then primed it, covered it in glue and put it in then spent the rest of the day drowning it in coats and coats of cement its. Its sealed know but it looks like a sin against spud guning :lol:
  • 0


iknowmy3tables
Major General
Major General

Posts: 1558
Joined: Fri Dec 15, 2006 3:57 pm
Location: maryland
Country: United States (us)
Reputation: 0

Unread postAuthor: Flying_Salt » Mon Jan 01, 2007 10:09 pm

I see you're about as good with primer as I am :roll:
Is it just me or does that pipe in the stock look a little yellowed?
  • 0

sgort87 wrote:I hereby present Flying_Salt with The one and only <a href="http://www.geocities.com/sgort87/ghetto">Ghetto Award!</a>
User avatar
Flying_Salt
Brigadier General
Brigadier General

Posts: 779
Joined: Mon Oct 09, 2006 4:57 pm
Location: Texas
Reputation: 0

Unread postAuthor: pyromanic13 » Mon Jan 01, 2007 10:09 pm

cool... but I think I threw up alittle in my mouth
  • 0

Movie dialogue: "The good die first."
Tom: "But most of us are morally ambiguous, which explains our random dying
patterns."

pyromanic13
Brigadier General
Brigadier General

Posts: 913
Joined: Wed Oct 19, 2005 7:54 pm
Reputation: 0

Unread postAuthor: judgment_arms » Mon Jan 01, 2007 10:12 pm

NICE! I like the multi-shot capability, don’t like the ball valves use two modded sprinkler valves that way all you have to do is load squeeze trigger one then trigger two, and repeat. The first one fills the chamber and acts like a safety the second fires the gun.
Oh and the wrap the tee in duck tape.
  • 0

Call me "Judge", it's easier to type.

Spud gun safety rules
User avatar
judgment_arms
Major General
Major General

Posts: 1272
Joined: Tue Oct 17, 2006 8:49 pm
Location: Not so beautiful North Carolina, but at least it’s the U.S.A.!
Reputation: 0

Unread postAuthor: iknowmy3tables » Mon Jan 01, 2007 10:16 pm

Is it just me or does that pipe in the stock look a little yellowed?

I geuss so I told you I used spare parts lying around (from my dad's plumbing inventory) so it is old, or you coul be talking about the third type of glue I used
  • 0


iknowmy3tables
Major General
Major General

Posts: 1558
Joined: Fri Dec 15, 2006 3:57 pm
Location: maryland
Country: United States (us)
Reputation: 0

Unread postAuthor: experament-u2 » Mon Jan 01, 2007 10:58 pm

good idear and i think just one spink valve for the main trigger would work and a ball for the chamber
  • 0

User avatar
experament-u2
Lieutenant Colonel
Lieutenant Colonel

Posts: 469
Joined: Tue Dec 26, 2006 11:18 pm
Reputation: 0

Unread postAuthor: iknowmy3tables » Mon Jan 01, 2007 10:59 pm

the multi shot mode is really weak and sprinkler valves are more bulky and require presure to work so a firing valve wouldn't be in my favor but a chamber to tank valve is a pretty good idea since its 1"inch and I have a spare sprinkler valve thanks I'll try it

edit: oh you posted befor I finished I understand why you say so but with the curent configeration and stats I think it should go vise versa
  • 0

Last edited by iknowmy3tables on Mon Jan 01, 2007 11:11 pm, edited 1 time in total.

iknowmy3tables
Major General
Major General

Posts: 1558
Joined: Fri Dec 15, 2006 3:57 pm
Location: maryland
Country: United States (us)
Reputation: 0

Sponsored

Sponsor



Unread postAuthor: MrCrowley » Mon Jan 01, 2007 11:58 pm

1:funny lol,good job on the primering,nice and clean :wink:
2:I wouldnt use the yellow pipe as the stock even if the air is jsut going through it.
3:Where's the 3' pipe you said you used for the chamber? I got excited there for a second....think I wet myself. :oops:



joking :P
  • 0

User avatar
MrCrowley
Moderator
Moderator

Posts: 10207
Joined: Fri Jun 23, 2006 10:42 pm
Location: Auckland, New Zealand
Country: New Zealand (nz)
Reputation: 4

Unread postAuthor: iknowmy3tables » Tue Jan 02, 2007 4:33 pm

whats wrong with yellowish pipe? ...is this somthing I have to research now
  • 0


iknowmy3tables
Major General
Major General

Posts: 1558
Joined: Fri Dec 15, 2006 3:57 pm
Location: maryland
Country: United States (us)
Reputation: 0

Unread postAuthor: MrCrowley » Tue Jan 02, 2007 5:14 pm

probably,alot of experienced spudders wouldnt recomend using it as its been effected by the elements and it weakens the pipe,something to do with the UV rays,but I've also had pipe turn yellow from sitting under the house for a few years but only one side was yellow....
  • 0

User avatar
MrCrowley
Moderator
Moderator

Posts: 10207
Joined: Fri Jun 23, 2006 10:42 pm
Location: Auckland, New Zealand
Country: New Zealand (nz)
Reputation: 4

Unread postAuthor: iPaintball » Thu Apr 12, 2007 3:20 pm

Dude, you made THE cleanest gun I've ever seen! :lol:
Seriously, though, I like it! PAINT IT!
  • 0

User avatar
iPaintball
Colonel
Colonel

Posts: 695
Joined: Sun Mar 04, 2007 8:37 pm
Reputation: 0
